PlantBuilder Model

See the source image



Using PlantBuilder, you can create conceptual 3D models of plants based on process description, plot layout, and libraries with definitions for equipment, pipeways and structures. The process description, or process model, relates to all things involved in the operation of a plant. For example, pieces of equipment are defined in the process model. The plot layout, or plot script, contains all the physical information of the plant. The equipment that is defined in the process model is given shape and location in the plot script.

Category:

Description

Introduction to PlantWise

This chapter briefly introduces the PlantWise software, the modules, and user interface basics. The succeeding sections describe how to use the PlantBuilder features of PlantWise to build and manipulate three-dimensional CAD models of process plants to support plant conceptual design and visualization.

See the source image



Front End Engineering and Design (FEED) fixes major plant project decisions. Very early in the process – while the P&ID is still in a state of flux – the plant has to be laid out for feasibility, permitting, real estate, and equipment considerations. At this stage, rapid 3D visualization of the contemplated plant layout is of high value for operations, safety, and maintenance review. Learn More

Powered by Bentley
